Lamella Plate Settler of Long Service Life in Industrial and Municipal Sewage Treatment

Basic Info

Model NO.	lamella clarifier
Type	Clarifier
Method	Combined Treatment
Usage	Industrial, Hospital
Product Name	Lamella Clarifeir
Treatment Capacity	3-60m3/Hour
Material	Carbon Steel/SS304/SS316L
Application	Wastewater Treatment
Function	Solid-Liquid Separation
Certificate	CE, ISO9001
Transport Package	Bulk Packing
Specification	Customized
Trademark	Gongyuan
Origin	China
HS Code	8421219990
Production Capacity	50 Sets/Month

Product Description

Lamella Clarifiers are highly efficient in removing heavy metals, ink and other contaminants from wastewater. GYE clarifiers feature integrated rapid mix tank and floc tank, eliminating the need to buy these tanks separately and providing a much simpler installation process. Our design ensures precise mixing so chemical coagulants can be used effectively and efficiently. Low shear mixers on the floc tanks help mix the coagulants without breaking the floc.

Feactures

• Stainless steel or Epoxy Coated Carbon Steel Tank
• Flash/Floc Mixing Tanks with Mixers
• Plate Packs
• Vertical Installation = Small Footprint
• Even Hydraulic Distribution Between Plates

Technical Data Sheet

Data Model	XBC-5	XBC-10	XBC-20	XBC-30	XBC-40	XBC-50	XBC-60	XBC-80	XBC-100
Capacity(m3/h)	5	10	20	30	40	50	60	80	100
Motor power(kw)	/		0.55
Scraper travelling speed(m/min)	/		2.26	2.1	2.3	2.5	2.55	2.64	2.82
Inclined plate quantity (pc)	10	15	38	46	50	56	58	60	64
Inclined plate size(mm)	1060*1200	1350*1465	750*1600	900*1600	1050*1600	1110*1600	1150*1800	1200*1200	1300*2000
Equivalent settling area(m2)	6.36	14.83	22.8	33.12	42	49.7	60.03	72	83.2
Length (mm)	2400	3000	3750	4050	4340	4525	4725	4975	5175
Width (mm)	1340	1740	2220	2520	2820	3090	3190	3290	3490
Height(mm)	3050	3200	4650	4650	4700	4900	5100	5330	5330
The height from inlet pipe to ground (mm)	1300	1250	3350	3350	3350	3600	3650	3825	3825
The height from outlet pipe to ground (mm)	2550	2680	3400	3400	3450	3450	3650	3825	3825
Inlet pipe(mm)	DN80	DN100	DN125	DN150	DN150	DN150	DN150	DN200	DN200
Outlet pipe(mm)	DN80	DN100	DN125	DN150	DN150	DN150	DN150	DN200	DN200
Sludge discharge pipe(mm)	DN150		DN200
Inspection manhole(mm)	/		DN600

This is just for reference, if any special request, please contact with our sales and technicians, thanks.



Applications

Industrial production wastewaterIndustrial chemistry--purification and concentrationPaper pulp and paper-making industryIron and steel industry--Phosphorus removalMetal hydroxides wastewaterPurification of biological cleaning processCirculating water from potato and vegetablesDust wiper wasterwater treatment from power plant
