Peripheral Drive and Central Drive Rotating Sludge Mud Scraper of Primary Clarifier Sewage Treatment Plant

Basic Info

Model NO.	QDZX/QDGN
Water After Treated	Discharge / Recycle
Service Life	10-30 Years
Certification	ISO9001/CE/SGS/BV
Voltage	220V/ 380V/ Customerized
Color	Grey/Silver/Blue/Balck/Customerized
Material	SS304 /SS316L/CS
Application	for Sedimentation Tank
Performance	Concentrating Sludge
Function	Solid-Liquid Separation
Motor	Centre Drive/Peripheral Drive
Character	Corrosion Resistance
Structure	Full/Half Bridge or Truss Type
Technical / Installation Support	Available
Visit Factory	Available
Transport Package	Standerd Export Package
Specification	QDZX3~16/QDGN8~35 or Customized
Trademark	QDEVU or Customized
Origin	China
HS Code	8421219990
Production Capacity	100/Month

Product Description

Product DescriptionApplication
Urban sewage treatment plantsWater worksChemical plantsFood processing plantsOther industrial wastewater treatment projects

Description

QDEVU sludge scraper has Full bridge, Half bridge and Truss type. Full/half bridge sludge scraper is suitable for the collection and discharge of sludge in circular radial sedimentation tank. It is mainly composed of working bridge, center rotating support, scraper scraper, diversion cylinder, driving mechanism, slag retaining and slag discharging device, etc., which can meet the requirements of DN5-DN50 kinds of specifications and different water quantity of sedimentation tank. The driving-type sludge scraper is suitable for collecting and discharging sludge from rectangular flat-flow sedimentation tank. It is mainly composed of working bridge, transmission device, scraper, sludge lifting pump and so on.

Working principle
Sludge scraper, sewage by central piers by diverting tube diffusion, mixture of massive particles by precipitation in the bottom sludge layer, the proportion of light floating in the liquid level, driving gear drives the work mud scraper bridge and set the sludge from pool week step by step toward the center of silt orifice discharge pool, sludge scraper along the guide tube will be floating scum on the liquid surface into the pool within weeks of discharge hopper, discharge outside the pool.

Features
1. Working bridge can be used half or full bridge, its material can be carbon steel, stainless steel, etc. 2. The scraper adopts rubber combination structure, scraping mud thoroughly. The scraper collects mud with spiral trajectory, which has good continuity and high efficiency of mud collection. 3. System control cabinet adopts outdoor type, safe and reliable, can be controlled randomly. 4. Smooth operation, safe and reliable work. 5. Simple structure, energy saving, convenient maintenance and management. 6. The size, material and other configuration of the equipment can be determined according to user requirements.

Projects

Product Parameters
QDZX Full Bridge Type Scraper Parameter

Model	Dia. Of Pond (m)	Depth. Of Pond (m)	Speed of mud scraper (m/min)	Power(kw/min)
QDZX-3	3.0	3.0	1-2	0.37
QDZX-4	4.0	3.5	1-2	0.75
QDZX-5	5.0	4.0	1-2	0.75
QDZX-6	6.0	4.0	1-2	0.75
QDZX-8	8.0	4.5	1-2	1.50
QDZX-10	10.0	4.5	1-2	1.50
QDZX-12	12.0	5.0	1-2	1.50
QDZX-14	14.0	5.0	2-3	1.50
QDZX-16	16.0	5.0	2-3	1.50

QDGN Half Bridge Type Scraper Parameter

Model	Dia. Of Pond (m)	Depth. Of Pond (m)	Speed of mud scraper (m/min)	Power(kw/min)
QDGN-8	8.0	3.0	1-2	0.55
QDGN-10	10.0	3.0	1-2	0.75
QDGN-12	12.0	3.5	1-2	0.75
QDGN-14	14.0	3.5	1-2	1.10
QDGN-16	16.0	3.5	1-2	1.10
QDGN-18	18.0	3.5	1-2	1.50
QDGN-20	20.0	3.5	1-2	1.50
QDGN-25	25.0	3.5	1-2	2.20
QDGN-30	30.0	4.0	1-3	2.20
QDGN-35	35.0	4.0	1-3	3.00

Company Profile Qingdao EVU Environmental and Engineering Equipment is established in 1999,it is one of scientific research design, equipment manufacture, installation, commissioning and training services as one integrated technology-oriented enterprises in water treatment industry. It is holding by Qingdao Spark Textile Machine which is a national Spark Industrial Group, national second-level and large-scale comprehensive enterprise group in China.We use the advanced technology and equipment over the world. Our main productions: Integrated Sewage Treatment Equipment, MBR Sewage Treatment Equipment(MBR), Electrocoagulation Sewage Treatment Plant(EC Plant), Reverse Osmosis Filteration Equipment(RO System), Dissolved Air Flotation Machine(DAF), Cavitation air Flotation Machine(CAF), Aerator, Screw Press Sludge Dewatering Machine, Automatic Chemical Dissolved and Dosing machine, Sludge Scraper, Slag Scraper, The micro bubble generator, USAB anaerobic reactor, Bar Screen, Sand Filter and so on series products. We have professional engineer support, high efficiency sales team and competitive price superiority, and attract customers from all over the world, we export to over 40 countries, including Europe, Poland, Serbia, Uruguay, Turkey, Russia, USA, Mexico, Brazil, Singapore, India, Egypt, Thailand, Middle east and South Africa. We based on "technological development, pollution remediation, wholeheartedly for customer services". We hope to cooperate with all customers from all over the world and build a better world together.FAQ

Q1:Are you a factory or trading company?

We are a real manufacturer who can offer you both the most competitive price and top quality products.

Q2:Where is your factory located? How can I visit there?

Our factory is located in Qingdao City Shandong Province, All our clients, from home or abroad, are warmly welcome to visit us!

Q3:Can you put my company brand (logo) on the products?

Yes,we support OEM/ODM service,the customize process as follows:1.Customers put forward personalized customization requirements.2.Our engineer draw the design draft.3.Customer confirm the design draft. 4.Factory start to produce shipment.

Q4:How to select right model?

You can tell us what you need, and we can help you choose the Model.Basic informations as follows:Wastewater type : Industry wastewater, Domestic wastewater, food wastewater or others)Capacity:m³/Day or m³/Hour?Raw water quality: SS, Oil & Grease &Fat & FOG, PH,BOD,COD content?Output water quality standard,for discharge or reuse?Local voltage and frequency?

Q5: What is your MOQ?

Normally, our MOQ is 1 set.

Q6:What is the payment term ?

TT and L/C are acceptable and TT will be more appreciated, 30% deposit, 70% balance payment before shipment.

Q7: We haven't imported before, can you ship the goods to our warehouse?

Yes. Although our normal trade term is EXW, FOB, CIF, we can also arrange logistics to your warehouse.

Q8:What is the delivery time of your factory?

5-10 days for general series products, meanwhile, batches products & customized products would need 15-30 days based on different situations.Contact us for the exact time.

Q9:How do you ensure the quality of your products?

Generally, our equipment are the most durable type in the industry, this is also the feature of the label impression for most of our customers at home or abroad.Skilled workers and strict quality control system can ensure every machine with best working performance.

Q10:How to assemble the equipment once we received it?

The CAD install instruction, assembly procedure and project case will be provided.,Of course our skilled installation engineers would go to your country and install the equipment if needed.

Q11: What is your product warranty ?After sales service?

The warranty is 12 months while the lifetime is 10-15 years under good maintenance.It is durable and anti-corrosion.Provide equipment certification and installation operating instructions.Provide one-year spare parts.Provide technical advisory services.Provide guidance staff for installation and commissioning.
